Item no. 341
Waste water test kit APS Soft
Accessories DPG07, DPG02, LM06
The flexible waste water test set: Leak test of waste water pipes in building installations.
Durable
You can rely on high quality
Check waste water
Leak test of wastewater pipes
Testing a condensing boiler stack and inflating the test bladder with bellows; test bladder in the cleaning opening of a waste water pipe.
Technical details
Services
The APS Soft optimally complements your RAU measuring devices for testing waste water pipes and condensing boilers.
You can find all the advantages here:
- Testing of wastewater pipes in accordance with DIN EN 1610 using the LC "air" method and a test pressure of 100 hPa
- Mainly used for testing newly installed wastewater pipes in domestic installations
- Test bladder for diameters 50-150 mm with pneumatic connection for the DPG07, DPG02 and LM06 TOUCH
- 3 shut-off bladders for pipe diameters 50, 100 and 50-150 mm
- Bellows for inflating the test and shut-off bladders
- Test time depending on the pipe diameter and selectable on the test device
- Save measurement results, transfer data to a PC and print out logs incl. Diagram on DIN A4 - only with DPG07 TOUCH and LM06 TOUCH
- Other possible applications: Leak testing of condensing stoves (chimney testing)
Scope of delivery
- Test bladder 50-150 mm
- 3 shut-off bladders 50 mm, 100 mm, 50-150 mm
- Bellows with pressure gauge
- Plastic case
EAN GTIN
APS SOFT: 4262453340348
WPS FUNK
Useful accessories
| Pressure pump up to 3 bar DPL | Air pressure pump for oil-free inflation up to 3 bar |
Item no. 73095
USB charging cable for WPS FUNK (new generation with magnetic plug and rotary switch for switching on and off since May 2024)
Charging cable for WPS FUNK from 5/24 with USB (type A) to magnetic adapter
Item no. 233
Cylindrical rubber sealing plug (blue) d = 12.0 mm
- for pipes DN12, 3/8″
- Suitable up to max. 4 bar test pressure
- The blue rubber is compressed by turning the wing nut, which closes the tube.
- For sealing pipe openings
Item no. 76058S
Shut-off bladder DN 100 with extension hose (1 m) and ball valve with plug nipple NW 2.7
Loadable up to max. 0.4 bar
Item no. 76059S
Shut-off bladder DN 50 with extension hose (1 m) and ball valve with plug nipple NW 2.7
Can be loaded up to max. 0.4 bar
Item no. 70175
Consisting of differential pressure test hose with NW 2.7 couplings and
silicone hose with 4.0 x 1.0 x 90 mm plug-in nozzle
Item no. 60103
Top cutting roller complete, screw connection and shim washers for HSG
Item no. 66151
Replacement plastic jaw set for WDF XP
incl. mounting material
Item no. 60105
Lower cutting roller complete, screw connection and shim washers for HSG
Item no. 60111
Cutting roller set with
- bottom complete, screw connection and 1 shim washer for HSG
- Top complete, screw connection and 3 shims for HSG
Item no. 75707
Set for DPG07 TOUCH consisting of
- 5x paper rolls
- 2x ribbons
- 1x leak detector spray
